Model Specifications 2 - Side Fan Design and Fan Under Design

There are two different designs of grain dryers which are side fan design or fan under design, you could choose basic, digital or fully automatic control systems.
Our world class of automatic grain drying and moisture control system has combined PLC and HMI technology, with touch screen controller, remote control with PC/Mobile Devices, measure, tracking and display moisture and temperature real time.
"Western Grain Dryer" SPECIFICATIONS FOR FAN UNDER DESIGN "Western Grain Dryer" SPECIFICATIONS FOR SIDE FAN DESIGN
CLICK HERE
MODEL
FAN UNDER DESIGN		 BPH DRY & COOL WHEAT 5 POINTS BPH DRY & COOL WHEAT 10 POINTS FAN UNDER DESIGN No. of FANS FAN UNDER DESIGN HP BU TOTAL HOLDING LEVELLING AUGER FILL HEIGHT LEVELLING DRAG FILL HEIGHT GRAVITY FILL HEIGHT
800-10 540 350 2 15 700 32 34 34
800-16 800 520 2 20 1000 44 46 46
1600-8 900 590 4 20 1178 28 30 32
1600-10 1085 705 4 30 1400 32 34 36
1600-12 1260 820 4 30 1625 36 38 40
1600-14 1400 930 4 30 1848 40 42 44
1600-16 1638 1000 4 40 2072 44 46 48
1600-18 1780 1157 4 60 2296 48 50 52
1600-20 2000 1260 4 60 2520 52 54 56
1600-22 2130 1380 4 60 2744 56 58 60
2400-8 1368 880 6 30 1764 28 30 34
2400-10 1630 1050 6 45 2100 32 34 38
2400-12 1890 1220 6 45 2436 36 38 42
2400-14 2150 1390 6 45 2772 40 42 46
2400-16 2410 1560 6 60 3108 44 46 50
2400-18 2669 1730 6 90 3444 48 50 54
2400-20 2930 1900 6 90 3780 52 54 58
2400-22 3192 2070 6 120 4116 56 58 62
2400-24 3450 2245 6 120 4452 60 62 66
3200-18 3562 2315 8 120 4594 N/A 50 56
3200-20 3910 2530 8 120 5043 N/A 54 60
3200-22 4255 2766 8 160 5490 N/A 58 64
3200-24 4605 2990 8 160 5939 N/A 62 68
3200-26 4950 3218 8 160 6386 N/A 66 72
4000-22 5316 3456 10 200 6860 N/A 58 N/A
4000-24 5752 3738 10 200 7420 N/A 62 N/A
4000-26 6184 4020 10 200 7980 N/A 66 N/A
4800-22 6380 4146 12 240 8232 N/A 58 N/A
4800-24 6902 4486 12 240 8904 N/A 62 N/A
4800-26 7422 4825 12 240 9576 N/A 66 N/A
Notes:
All dryer width standard 8 feet 2 inch.
All figures are approximate and very with variety, grade, contamination, wheather conditions, maturity and test weights.
Specifications subject to change without notice.
